IP56 SERIES WEATHER PROTECTED SWITCHES
- Cat. No: WPS/WPT
Technical Information
Features | Poles | Catalogue Number |
- Suitable for any external application | 1 | WPS20 |
- Easier termination and spacious wiring room | 1 | WPS35 |
- Fixed Earth and Neutral connector bars with dual clamping screws per tunnel | 3 | WPT20 |
- Insulating caps that protect base mounting screws from any live cables | 3 | WPT35 |
- Dual top and bottom 25mm screwed conduit entries that allows four ways to surface wire the switch | 3 | WPT55 |
- Deep moulded barriers that protect operating lever from pyhsical abuse accidental switching | 3 | WPT63 |
